Rezervor de stocare nou pentru transport de combustibili CS 2282 FUEL TANK 3000 LITERS 110%

Outdoor TANK for diesel fuel, MI homologated in compliance with DM 22/11/2017, with horizontal cylindrical axis on anti-rolling support brackets, built in high-grade carbon steel sheet 3 mm thick, treated with a layer of anti-rust and a finishing enamel layer, hydraulically tested and equipped with the following accessories: manhole diam. 400 mm. with bolts and gasket, 1 "½ bronze flame trap breather, flow level indicator, 3" quick-grip load connection, 3 "load limiting valve, internal diesel level control device, loading access platform (only 9000 lt.), earthing and equipotentiality socket located near the support feet, drain sleeves on the bottom with 3/4 "safety cap, 1" ball cock, valve 1 "non-return valve,

BASIN in carbon steel sheet with self-supporting bottom frame already prepared for bolting to the foot of the tank, suitable for positioning on any terrain, designed to contain 110% of the capacity of the tank in compliance with the safety requirements, equipped with grounding, with drain plug, totally treated with a layer of anti-rust and a finishing enamel

DISPENSER in painted steel box with tamper-proof key door, equipped with from self-priming electric pump with by-pass and built-in filter, motor capacity 50 LT / MIN. 0.5 HP– 2800 g / min. - 220 V. single-phase 50 Hz, K33 liter-counter (accuracy +/- 2% in the flow range) for private use with partial resettable and progressive totalizer, ¾ "length 4 m flexible dispensing hose, automatic nozzle with 1 connector "Articulated, 1" suction pipe, electrical control panel with IP55 protection degree with pump blocking device at minimum level.

BOX total cover for the tank (instead of the roof) in galvanized and corrugated self-supporting sheet, equipped with tubular for fixing inside the containment basin, n.01 ventilation grille n.04 eyebolts lifting, front door with key lock, external vent
